Name: High Thermal Conductive 2.8W Two Component Potting Silicone Adhesive For Industrial Control
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIG680-28AB
Price: 50.00 USD
Availability: InStock

Casa Prodotti Adesivo conduttivo termico del silicone

High Thermal Conductive 2.8W Two Component Potting Silicone Adhesive For Industrial Control

Dettagli:

Luogo di origine:	Cina
Marca:	Ziitek
Certificazione:	RoHS
Numero di modello:	TIG680-28AB

Termini di pagamento e spedizione:

Quantità di ordine minimo:	10KG
Prezzo:	1-100USD/KG
Imballaggi particolari:	1kg/can
Tempi di consegna:	3-8 giorni lavorativi
Termini di pagamento:	T/T
Capacità di alimentazione:	10000KG/Month

Contatto

Descrizione di prodotto dettagliata

Nome dei prodotti:	Adesivo siliconico bicomponente ad alta conduttività termica da 2,8 W per il controllo industriale	Densità:	2.95
Materiale:	Adesivo in silicone	Colore:	grigio
Durezza:	25 (riva A)	Applicazione:	Controllo industriale, trasformatore, bobina
Conduttività termica:	2,8 W/mK	Parola chiave:	Compound per la preparazione del vaso

High Thermal Conductive 2.8W Two Component Potting Silicone Adhesive For Industrial Control

TIG^®680-28AB Series is a two-component high thermal conductivity silicone sealant with room temperature curing, long working time, and flame retardant properties. This product is particularly suitable for sealing capacitors and small electronic devices. Its excellent flexibility properties enable it to provide excellent cushioning protection for coating materials. The low viscosity characteristic enables the thermal conductive sealant to cover the surface more comprehensively, greatly improving the heat transfer efficiency of the heating element or the entire printed circuit board to the metal shell or heat dissipation plate,thereby improving the performance and service life of electronic components.

Feature

> Good thermal conductivity: 2.8W/mK
> Good insulation performance
> Good elasticity
> Lower shrinkage
> Low viscosity,easy gas emissions
> Good solvent resistance and waterproof performance
> Longer working hours
> Excellent high and low temperature resistance
> No odor release during the curing process

Application

> Industrial control,transfomer,coil, amplifier, high voltage package,relay, high current junction box,etc
> Heat sink assembly, thermal sensor potting,thermal conductive product potting
> Heat conduction between the battery cell and the cold tube
> LED and power drive potting

Typical Properties of TIG^®680-28AB Series
Material Properties (Before Curing)
Property	Numerical	Test Method
Color/Part A	White	Visual
Color/Part B	Gray	Visual
Part A Viscosity (mPa.s)	7000	GB/T 10247
Part B Viscosity (mPa.s)	8000	GB/T 10247
Mix Ratio	1:1	Ziitek Test Method
Shelf life	6 months(Unopened)	Ziitek Test Method
Cure Schedule
Pot Life @25℃	30~45 mins	Ziitek Test Method
Cure @70℃	20~30 mins	Ziitek Test Method
Cure Material Properties
Color	Gray	Visual
Hardness (Shore A)	25	ASTM D2240
Density (g/cm³)	2.95	ASTM D792
Recommended Operating temperature (℃)	-45 ~200	*****
Flame Rating	V-0	UL 94
Thermal Conductivity (W/mK)	2.8	ASTM D5470
Breakdown Voltage (V/mm)	≥8000	ASTM D149
Dielectric Constant @1MHz	6.0~8.0	ASTM D150
Volume Resistivity (Ohm·cm)	1.0x10¹³	ASTM D257

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials.

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract.

5.Free sample offer.

6.Quality assurance contract.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
