High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications

High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications

  • High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications
  • High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications
High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications
Dettagli:
Luogo di origine: Cina
Marca: Ziitek
Certificazione: UL
Numero di modello: TIF050-11-1
Termini di pagamento e spedizione:
Quantità di ordine minimo: 1000 tubi
Prezzo: 0.1-100USD/KG
Imballaggi particolari: 300 cc/pcs, 6 pcs/scatola
Tempi di consegna: 3-8 giorni di lavoro
Termini di pagamento: T/t
Capacità di alimentazione: 10000KG/Month
Contatto
Descrizione di prodotto dettagliata
Nome dei prodotti: Gel termico ad alta conduttività 5.0W/MK Gel conduttivo termico isolante adatto per applicazioni PCB Peso specifico: 3.25 g/cc
Colore: Grigio scuro Materail: Materiale di silicio riempito di ceramica
Tensione di rottura (V/mm): ≥6000 Conducibilità termica: 5.0W/m-k
Parole chiave: Gel termico Applicazione: Applicazioni PCB
Costante dielettrica @1MHz: 7,7

High Conductivity Thermal Gel 5.0W/MK Insulation Thermal Conductive Gel Suitable For PCB Applications



TIF®050-11-1 is a thermally conductive paste with excellent interface thermal resistance characteristics and outstanding plasticity, capable of fully meeting the strict thermal management performance requirements of various designs; this material has extremely low hardness, possesses free-forming ability, and is easy to construct and assemble, demonstrating good stability in high-temperature environments. Its low-stress characteristics are particularly suitable for electronic devices that require high precision and high reliability, effectively reducing the mechanical stress on sensitive components during assembly and operation, ensuring the long-term stable operation of products in various application  environments.



Feature



> Thermal conductivity: 5.0 W/mK
> Low stress, protect sensitive components.
> Strong plasticity. good stability
> Superior dielectric properties



Application



> Power module
> LED backlight module, LED lighting
> High speed hardware driver
> Micro heat pipe
> Vihicel enginee controller
> Telecom industry
> Semiconductor automatic laboratory equipment



TIF®050-11-1 Typical Properties
Property Value Test method
Color Dark Gray Visual
Construction & Composition Ceramic filled silicon material ******
Density(g/cm³) 3.25g/c ASTM D792
Thermal conductivity 5.0W/mK ASTM D5470
Breakdown Voltage (V/mm) ≥6000 ASTM D149
Dielectric constant @1MHz 7.7 ADTM D150
Flame Rating V-0 UL 94
Volume resistivity(Ohm.cm) 8.0 X 1013 ASTM D257



Packing details

30 cc/pc, 98 pc/box;

300 cc/pc , 6 pc/box

We offer the custom packaged in syringes for automated despensing applications.

Please contact us for confirming.
